Product Overview
Item specifics:
- Brand Name:HoldPeak
- DIY Supplies:Electrical
- Display Type:Digital Display
- Measuring Inductance Range:-
- Operating Temperature:0 - 40 ℃
- Dimensions:15 * 11 * 3.6cm
- Model Number:HP-37C
- Measuring Resistance Range:600/6K/60K/600K/6M/60M Ohm
- Measuring Capacitance Range:9.99nF/99.99nF/999.9nF/9.99uF/99.99uF/999.9uF/9.99
- Operating Mode:Auto and Manual
- AC Voltage:6V/60V/600V
- DC Voltage:600mV/6V/60V/600V
- AC Current:600uA/6000uA/60mA/600mA/6A/10A
- DC Current:600uA/6000uA/60mA/600mA/6A/10A
- Measuring Temperature range:-20-1000 C
- Measuring Frequency range:9.999Hz/99.99Hz/999.9Hz/9.999KHz/99.99KHz/999.9KHz
- Measuring Duty cycle range:0.1% -99.9%
- Product Size:15 * 11 * 3.6cm
- Battery type:9V(6F22)*1(not included)
- Battery Test:Yes
- Data Hold:Yes
- Auto Back-Light:Yes
- Auto Power Off:Yes
- Relative Value:Yes
- Diode Test:Yes
- Temperature Unit Select C/F:YesProduct Description
Features:
Specification:
The multimeter is characterized at slim size, portable, stable performance and anti-dropping capacity.
Using 6000 counts digit LCD monitor with character 25mm high, they offer clear readings. With overall
circuitry design centering on large-scale IC A/D converters in conjunction and over-load protection circuit,
the meters give excellent performance and exquisite making as a handy utility instrument.The meters
can be used to measure DC & AC voltage, DC & AC current, resistance, capacitor, frequency, cycle,
temperature, battery test, Non Contact AC Voltage (NCV) detection, positive diode voltage fall and
audible continuity.
Display: 6000
DC & AC voltage, DC & AC current Measurement
Resistance, Capacitor, Frequency, Cycle, Temperature, Battery Test
Range Select: Auto and Manual
Data Hold
Auto Back-Light
Auto Power Off
NCV
Relative Value
Diode Test
Temperature Unit Select ℃/℉Model Number: HP-37C
Operating Temperature: 0 - 40 ℃
Operating Humidity: ≤75%RH
Storage Condition: -20~60℃
Storage Humidity: ≤80%RH
Battery type: 9V(6F22)*1(not included)
Measuring DC voltage range: 600mV/6V/60V/600V
Measuring AC voltage range: 6V/60V/600V
Measuring DC current range: 600uA/6000uA/60mA/600mA/6A/10A
Measuring AC current range: 600uA/6000uA/60mA/600mA/6A/10A
Measuring Resistance range: 600Ω/6KΩ/60KΩ/600KΩ/6MΩ/60MΩ
Measuring Capacitance range: 9.99nF/99.99nF/999.9nF/9.99uF/99.99uF/999.9uF/9.999mF/99.99mF
Measuring Temperature range: -20-1000 ℃
Measuring Frequency range: 9.999Hz/99.99Hz/999.9Hz/9.999KHz/99.99KHz/999.9KHz/9.999MHz
Measuring cycle range: 0.1% -99.9%
Product Size: 15 * 11 * 3.6cm
Package includes:
1 x HP-37C Multimeter
1 x English Manual
1 x Test Leads
1 x Temperature Test Probe
